| 基本尺寸 | 基本额定负荷 | 现代号 | 重量 | 结构 | ||||||||
| Principal dimensions | Basic load ratings | Designations | Weight | |||||||||
| 动 | 静 | |||||||||||
| d | D | B | C | C1 | K | rsmin | r1smin | dyc_Cr | stc_Cor | |||
| mm | KN | kg | ||||||||||
| 120 | 180 | 70 | 36 | 32 | 2 | 248 | 335 | 802824-1 | 5 | 2 | ||
| 130 | 200 | 85 | 42 | 2 | 2 | 280 | 385 | 802826-1 | 7.5 | 2 | ||
| 140 | 210 | 85 | 42 | 2 | 2 | 325 | 450 | 802828-1 | 8 | 2 | ||
| 150 | 225 | 90 | 45 | 2.1 | 2.1 | 350 | 500 | 802830-1 | 10 | 2 | ||
| 160 | 240 | 95 | 48 | 2.1 | 2.1 | 400 | 570 | 802832-1 | 12 | 2 | ||
| 170 | 260 | 105 | 54 | 2.1 | 2.1 | 465 | 690 | 802834-1 | 15 | 2 | ||
| 180 | 280 | 110 | 60 | 2.1 | 2.1 | 520 | 760 | 802836-1 | 21 | 2 | ||
| 200 | 310 | 120 | 66 | 2.1 | 2.1 | 710 | 1060 | 802840-1 | 26 | 2 | ||
| 220 | 393.7 | 156 | 90.5 | 2 | 2 | 1210 | 1800 | 802844 | 85 | 1 | ||
| 220 | 340 | 135 | 72 | 3 | 3 | 870 | 1360 | 802844-1 | 35 | 2 | ||
| 240 | 440 | 156 | 90.5 | 3 | 3 | 1320 | 2040 | 802848 | 100 | 1 | ||
| 240 | 360 | 135 | 72 | 3 | 3 | 860 | 1370 | 802848-1 | 39 | 2 | ||
| 260 | 400 | 145 | 82 | 4 | 4 | 1060 | 1700 | 802852-1 | 51 | 2 | ||
| 280 | 420 | 145 | 82 | 4 | 4 | 1050 | 1710 | 802856-1 | 56 | 2 | ||
| 300 | 558.8 | 220 | 139.7 | 5 | 5 | 2330 | 1710 | 802860 | 200 | 1 | ||
| 300 | 460 | 180 | 95 | 4 | 4 | 1440 | 3250 | 802860-1 | 83 | 2 | ||
| 320 | 622.37 | 272 | 160.4 | 7.5 | 7.5 | 2920 | 4400 | 802860-1 | 83 | 2 | ||
| 320 | 480 | 180 | 95 | 4 | 4 | 1530 | 2500 | 802864 | 330 | 1 | ||
| 340 | 520 | 190 | 106 | 5 | 5 | 1720 | 2850 | 802868-1 | 111 | 2 | ||
| 400 | 600 | 220 | 148 | 7.5 | 7.5 | 2550 | 4900 | 802880 | 200 | 1 | ||
| 400 | 600 | 220 | 148 | 7.5 | 7.5 | 2550 | 4900 | 802880-1 | 210 | 2 | ||
| 420 | 740 | 320 | 148 | 7.5 | 7.5 | 4020 | 6700 | 802884 | 650 | 1 | ||
| 420 | 740 | 320 | 190 | 7.5 | 7.5 | 4020 | 6700 | 802884-1 | 660 | 2 | ||
| 500 | 850.9 | 360 | 210 | 7.5 | 7.5 | 5010 | 9000 | 8028/500 | 800 | 1 | ||
| 500 | 850.9 | 360 | 210 | 7.5 | 7.5 | 5010 | 9000 | 8028/500-1 | 820 | 2 | ||
| 580 | 750 | 160 | 90 | 5 | 5 | 1190 | 2280 | 8028/580 | 130 | 1 | ||
| 580 | 750 | 160 | 90 | 5 | 5 | 1190 | 2280 | 8028/580-1 | 135 | 2 | ||
| 630 | 794 | 190 | 88 | 5 | 5 | 1760 | 4300 | 8028/630-1 | 160 | 1 | ||
| 630 | 794 | 190 | 88 | 5 | 5 | 1760 | 4300 | 8028/750-2 | 170 | 2 | ||
| 750 | 920 | 165 | 78 | 4 | 4 | 1680 | 4050 | 8028/750-2 | 190 | 3 | ||
| 750 | 920 | 165 | 78 | 4 | 4 | 1380 | 4050 | 8028/750-3 | 200 | 4 | ||
| 900 | 1090 | 150 | 85 | 6 | 6 | 1720 | 4250 | 8028/900-4 | 240 | 5 | ||
| 1000 | 1220 | 170 | 100 | 6 | 6 | 2700 | 6400 | 8028/1000-4 | 345 | 5 | ||
| 1120 | 1360 | 210 | 106 | 6 | 6 | 3140 | 7650 | 8028/1120-2 | 470 | 3 | ||
| 1120 | 1360 | 210 | 106 | 6 | 6 | 3140 | 7650 | 8028/1120-3 | 475 | 4 | ||
| 1400 | 1700 | 225 | 132 | 6 | 6 | 4950 | 13200 | 8028/1400-4 | 905 | 5 | ||
| 360 | 460 | 225 | 164 | 61 | 6x1 | 4 | 1140 | 2900 | 822872 | 90 | ||
| 400 | 600 | 328 | 244 | 84 | 8x10 | 5 | 2240 | 4300 | 822880 | 285 | ||
| 440 | 600 | 380 | 290 | 90 | 8x10 | 7.5 | 2810 | 6950 | 822888 | 295 | ||
| 440 | 600 | 420 | 330 | 130 | 8x10 | 7.5 | 2810 | 6950 | 822888X2 | 310 | ||
| 460 | 596.9 | 280 | 200 | 80 | 8X7.5 | 7.5 | 1470 | 3350 | 822892 | 130 | ||
| 500 | 635 | 310 | 228 | 82 | 8X10 | 7.5 | 2240 | 5850 | 8228/500 | 220 | ||
| 500 | 635 | 340 | 260 | 82 | 8X10 | 7.5 | 2510 | 6800 | 8228/500X2 | 270 | ||
| 540 | 705 | 380 | 290 | 90 | 8X10 | 7.5 | 3140 | 8500 | 8228/540 | 370 | ||
| 560 | 730 | 350 | 260 | 90 | - | 7.5 | 2860 | 7350 | 8228/560 | 355 | ||
| 600 | 775 | 380 | 278 | 102 | 8X10 | 7.5 | 3140 | 8500 | 8228/600 | 430 | ||
| 610 | 780 | 380 | 290 | 90 | 8X10 | 7.5 | 3520 | 10000 | 8228/610 | 435 | ||
| 640 | 805 | 380 | 290 | 90 | 8X10 | 7.5 | 3520 | 10400 | 8228/640 | 440 | ||
| 820 | 990 | 380 | 290 | 90 | 8X10 | 7.5 | 3910 | 12900 | 8228/820 | 565 | ||
