SJ系列英制滚针轴承
MR HJ SJ NCS系列 | ||||||||
轴承型号 | 内径/mm | 外径/mm | 高度/mm | |||||
INA | McGill | RBC | Torrington | IKO | ||||
NCS1012 | MR10N | SJ7133 | HJ101812 | BR101812 | 15.875(0.625) | 28.575(1.125) | 19.05(0.75) | |
MR10 | SJ7134 | HJ101816 | BR101816 | 15.875(0.625) | 28.575(1.125) | 25.4(1) | ||
NCS1212 | MR12N | SJ7153 | HJ122012 | BR122012 | 19.05(0.75) | 31.75(1.25) | 19.05(0.75) | |
NCS1216 | MR12 | SJ7154 | HJ122016 | BR122016 | 19.05(0.75) | 31.75(1.25) | 25.4(1) | |
NCS1412 | MR14N | SJ7173 | HJ142212 | BR142212 | 22.225(0.875) | 34.925(1.375) | 19.05(0.75) | |
NCS1416 | MR14 | SJ7174 | HJ142216 | BR142216 | 22.225(0.875) | 34.925(1.375) | 25.4(1) | |
NCS1612 | MR16N | SJ7193 | HJ162412 | BR162412 | 25.4(1) | 38.1(1.5) | 19.05(0.75) | |
NCS1616 | MR16 | SJ7194 | HJ162416 | BR162416 | 25.4(1) | 38.1(1.5) | 25.4(1) | |
NCS1816 | MR18N | SJ7214 | HJ182616 | BR182616 | 28.575(1.125) | 41.275(1.625) | 25.4(1) | |
NCS1820 | MR18 | SJ7215 | HJ182620 | BR182620 | 28.575(1.125) | 41.275(1.625) | 31.75(1.25) | |
NCS2016 | MR20N | SJ7234 | HJ202816 | BR202816 | 31.75(1.25) | 44.45(1.75) | 25.4(1) | |
NCS2020 | MR20 | SJ7235 | HJ202820 | BR202820 | 31.75(1.25) | 44.45(1.75) | 31.75(1.25) | |
NCS2216 | MR22N | SJ7254 | HJ223016 | BR223016 | 34.925(1.375) | 47.625(1.875) | 25.4(1) | |
NCS2220 | MR22 | SJ7255 | HJ223020 | BR223020 | 34.925(1.375) | 47.625(1.875) | 31.75(1.25) | |
NCS2416 | MR24N | SJ7274 | HJ243316 | BR243316 | 38.1(1.5) | 52.388(2.0625) | 25.4(1) | |
NCS2420 | MR24 | SJ7275 | HJ243320 | BR243320 | 38.1(1.5) | 52.388(2.0625) | 31.75(1.25) | |
NCS2616 | MR26N | SJ7294 | HJ263516 | BR263516 | 41.275(1.625) | 55.562(2.1875) | 25.4(1) | |
NCS2620 | MR26 | SJ7295 | HJ263520 | BR263520 | 41.275(1.625) | 55.562(2.1875) | 31.75(1.25) | |
NCS2816 | MR28N | SJ7314 | HJ283716 | BR283716 | 44.45(1.75) | 58.738(2.3125) | 25.4(1) | |
NCS2820 | MR28 | SJ7315 | HJ283720 | BR283720 | 44.45(1.75) | 58.738(2.3125) | 31.75(1.25) | |
NCS3020 | MR30 | SJ7335 | HJ303920 | BR303920 | 47.625(1.875) | 61.912(2.4375) | 31.75(1.25) | |
MR31 | SJ7345 | 49.2125(1.9375) | 63.5(2.5) | 31.75(1.25) | ||||
MR32N | SJ7354 | HJ324116 | BR324116 | 50.8(2) | 65.088(2.5625) | 25.4(1) | ||
NCS3220 | MR32 | SJ7355 | HJ324120 | BR324120 | 50.8(2) | 65.088(2.5625) | 31.75(1.25) | |
NCS3624 | MR36N | SJ8406 | HJ364824 | BR364824 | 57.15(2.25) | 76.2(3) | 38.1(1.5) | |
MR36 | SJ8407 | HJ364828 | BR364828 | 57.15(2.25) | 76.2(3) | 44.45(1.75) | ||
NCS4024 | MR40N | SJ8446 | HJ405224 | BR405224 | 63.5(2.5) | 82.55(3.25) | 38.1(1.5) | |
MR40 | SJ8447 | HJ405228 | BR405228 | 63.5(2.5) | 82.55(3.25) | 44.45(1.75) | ||
NCS4424 | MR44N | SJ8476 | HJ445624 | BR445624 | 69.85(2.75) | 88.9(3.5) | 38.1(1.5) | |
MR44 | SJ8477 | HJ445628 | BR445628 | 69.85(2.75) | 88.9(3.5) | 44.45(1.75) | ||
NCS4824 | MR48N | SJ8516 | HJ486024 | BR486024 | 76.2(3) | 95.25(3.75) | 38.1(1.5) | |
MR48 | SJ8517 | HJ486028 | BR486028 | 76.2(3) | 95.25(3.75) | 44.45(1.75) | ||
NCS5228 | MR52 | SJ9567 | HJ526828 | BR526828 | 82.55(3.25) | 107.95(4.25) | 44.45(1.75) | |
MR56N | SJ9607 | 88.9(3.5) | 114.3(4.5) | 44.45(1.75) | ||||
MR56 | SJ9608 | HJ567232 | BR567232 | 88.9(3.5) | 114.3(4.5) | 50.8(2) | ||
MR60 | SJ9648 | HJ607632 | BR607632 | 95.25(3.75) | 120.65(4.75) | 50.8(2) | ||
MR64 | SJ9688 | HJ648032 | BR648032 | 101.6(4) | 127(5) | 50.8(2) | ||
NCS6832 | MR68 | SJ9728 | HJ688432 | BR688432 | 107.95(4.25) | 133.35(5.25) | 50.8(2) | |
MR72 | SJ6769 | HJ729636 | 114.3(4.5) | 152.4(6) | 57.15(2.25) | |||
MR80 | SJ6849 | HJ8010436 | 127(5) | 165.1(6.5) | 57.15(2.25) | |||
MR88N | SJ6918 | HJ8811240 | 139.7(5.5) | 177.8(7) | 63.5(2.5) | |||
MR88 | SJ6919 | HJ8811248 | 139.7(5.5) | 177.8(7) | 76.2(3) | |||
MR96N | SJ6925 | HJ9612040 | 152.4(6) | 190.5(7.5) | 63.5(2.5) | |||
MR96 | SJ6926 | HJ9612048 | 152.4(6) | 190.5(7.5) | 76.2(3) | |||
MR104N | SJ6935 | HJ | 165.1(6.5) | 203.2(8) | 63.5(2.5) | |||
MR104 | SJ6936 | HJ | 165.1(6.5) | 203.2(8) | 76.2(3) | |||
MR116 | SJ2326 | HJ | 184.1(7.25) | 231.775(9.125) | 76.2(3) | |||
MR124 | SJ2426 | HJ | 196.85(7.75) | 244.475(9.625) | 76.2(3) | |||
MR132 | SJ2526 | HJ | 209.55(8.25) | 257.175(10.125) | 76.2(3) | |||
MR140 | SJ2626 | HJ | 222.25(8.75) | 269.875(10.625) | 76.2(3) | |||
MR148 | SJ2726 | HJ | 234.95(9.25) | 282.575(11.125) | 76.2(3) |
