HF系列单向离合器轴承
轴径Shaft Diameter | 离合器型号 | 重量 Mass 近似Approx | 外形尺寸 | 转动力矩Torgue Ma | 极限转速 | |||||
Clutch Designation | Borndary Dimensions | Limiting Speed | ||||||||
塑料弹簧 | 不锈钢簧片 | Fw | D | C | 轴旋转 Rotating Shaft Min-1 | 外圈旋转 Rotatng Outer Ring Min-1 | ||||
mm | Plastic Springs | Steel Springs | g | mm | Nm | rpm | ||||
HF | ||||||||||
3 | HF0306KF | 0.9 | 3 | 6.5 | 6 | 0.2 | 36000 | 7000 | ||
4 | HF0406KF | -- | 1 | 4 | 8 | 6 | 0.34 | 34000 | 8000 | |
HF0406KFR | -- | 1 | 4 | 8 | 6 | 0.1 | 34000 | 8000 | ||
6 | HF0608KF | 2.8 | 6 | 10 | 8 | 1.5 | 20000 | 11000 | ||
HF0612KF | HF0612 | 3 | 6 | 10 | 12 | 1.76 | 23000 | 13000 | ||
HF0612KFR | HF0612 | 3 | 6 | 10 | 12 | 1.76 | 23000 | 13000 | ||
HF061210 | 3.5 | 6 | 12 | 10 | 3 | 20000 | 13000 | |||
8 | HF0812KF | HF0812 | 3.5 | 8 | 12 | 12 | 3.15 | 17000 | 12000 | |
HF0812KFR | HF0812 | 3.5 | 8 | 12 | 12 | 4 | 17000 | 12000 | ||
-- | HF061210 | 3.2 | 8 | 12 | 10 | 3 | 16000 | 12000 | ||
-- | HF081410 | 3.6 | 8 | 14 | 10 | 4.6 | 15000 | 11000 | ||
-- | HF081610 | 4.1 | 8 | 16 | 10 | 5.5 | 15000 | 11000 | ||
-- | HF081412 | 4 | 8 | 14 | 12 | 5 | 16000 | 12000 | ||
10 | HF1012KF | HF1012 | 4 | 10 | 14 | 12 | 5.3 | 14000 | 11000 | |
HF1012KFR | HF1012 | 4 | 10 | 14 | 12 | 1.5 | 14000 | 11000 | ||
12 | -- | HF1216 | 11 | 12 | 18 | 16 | 12.2 | 11000 | 8000 | |
14 | -- | HF1416 | 13 | 14 | 20 | 16 | 17.3 | 9500 | 8000 | |
16 | -- | HF1616 | 14 | 16 | 22 | 16 | 20.5 | 8500 | 7500 | |
18 | -- | HF1816 | 16 | 18 | 24 | 16 | 24.1 | 7500 | 7500 | |
20 | -- | HF2016 | 17 | 20 | 26 | 16 | 28.5 | 7000 | 6500 | |
25 | -- | HF2520 | 30 | 25 | 32 | 20 | 66 | 5500 | 5500 | |
30 | -- | HF3020 | 36 | 30 | 37 | 20 | 90 | 4500 | 4500 | |
35 | -- | HF3520 | 40 | 35 | 42 | 20 | 121 | 3900 | 3900 | |
