新昌县万久精工机械有限公司

LB-196 铜箔丝缠绕机/包覆机

LB-196 Tinsel Copper Wire Covering Machine

特点：

1. 机器采用空心锭子，提高转速。

2. 采用PLC人机界面控制系统，触摸屏输入，操作便捷

3. 龙带传动，保证空心锭子转速一致

4，伺服电机同步带电子成形，保证低速排线稳定性，精确，美观。

Features:

1. Use Hollow Spindle. It can keep the machine high speed running.

2. Fully computerized System, HMI, Easy for operation.

3. Tangential Belt drive, confirm each spindle in the same speed.

4. Servo Motor E-traverse System, Keep the machine stable, high precision, and final products good appearance

产品原料：

导体材质有：裸铜、镀锡铜、合金铜、镀银铜、镀镍铜、镀锡合金铜等，

中心纤维丝可用尼龙丝，芳纶，防弹丝，玻璃纤维丝，可乐丽，杜邦丝， 克丝，涤纶丝等各种纤维丝线单支完成外径：0.05MM-----0.50MM。

单次或双次包覆都可以。

Material:

Conductive material: Bare Copper, Tin Plated Copper, Silver plated Copper etc.

Core material （carrier thread）: Aramide (Kevlar,Nomex), Glass fiber, High tenacity yarn.

Round single wire diameter: ranging from Ø 0.05 mm to Ø 0.50 mm

Single or double tinsel (one or two flat copper wires, spun around a carrier thread)

终产品应用：

产品大量应用于充电桩，机器人、医疗、高端耳机线音响线、金属导电布等高柔性、高强度、高抗摇摆性的电缆导体机构中、

以满足线缆导体耐高温、抗摇摆性等不同极端环境情况，条干匀称，导电性能良好

Application:

# Health care

# Robot, Robotic arms

# Charging Piles.

# High Quality headphone. Coil-cords for loudspeakers.

# Conductive fabric

Very good flexibility， Very good tensile strength， Good Flex life
